Industrial Meat Vacuum tumbler Marinator​

Model NO. : 50l/00l/200l/500l/1000l/1200l/1500l
1. Automatic Control (With Temperature Display)
2. Functions Can Be Customized.
3. Air Circulation System Design.
4. Utilizes A Wood Chip Smoking System.
5. Features A Double-Layer Stainless Steel Structure.
6. Cylinder Performance. Stable And Reliable.
Energy source
Electric ,steam
Material
304 stainless steel
Application
Mixing
Production Capacity
Depends On You
Power(W)
1.5-5.5kw
Voltage
380V
Quantity:
add to cart
Send Inquiry
Product advantages
    The Vacuum tumbler Marinator​ will have tenderized raw meat protein in full contact with salt water, accelerate the dissolution of protein and interaction, to increase the adhesion between meat and meat, and can make meat color, improve meat tenderness and water retention, improve meat quality.
    Any type of meat vacuum tumbler​ has the adjustment of total working time, working time, suspension time and vacuum degree, and some have the time control of positive and negative rotation.The optimal temperature of the working environment when rolling is 0~3°C
Product Specifications




Product Parameters :
Model
Power (kw)
Dimensions
 Body diameter
 Barrel length
Voltage: 380V, three phases Speed: 9 RPM Plus frequency conversion +1800 yuan, speed adjustable 0-11 RPM, Vacuum degree ≦-0.8mp,
Computer board control (Chinese or English) There are single and V-shaped ruler options Forward rolling reverse
GR-50L
1.5
910*730*850
500
500
GR-100L
1.5
1130*712*1100
600
600
GR-200L
2.25
1450*800*1450
900
620 head 240*2
GR-300L
2.25
1760*1000*1500
1000
750 head 270*2
GR-500L
2.95
2000*1000*1550
1000
1000 head 270*2
GR-600L
2.95
2060*1100*1570
1000
1200 head 270*2
GR-800L
4.5
2600*1200*1800
1200
1240 head 320*2
GR-1000L
5.5
3100*1350*1950
1200
1500 head 320*2
GR-1200L
5.5
3200*1400*1870
1400
1200
Main Applications:
